Our diff drop kits run from $140 to $590 for the kit, and $604 to $1,199 fitted through Click and Fit. The spread comes down to platform complexity. Fitting one at the same time as your lift is the cheapest path, because the front end is already apart.

Straight numbers first, then what drives them. Every price below is from our current range, in AUD, and correct at the time of writing. You can check any of them on the diff drop kits pages, and the fitted price includes professional installation through Click and Fit at over 200 locations nationwide.

Our current prices

Kit

Part

Kit only

Fitted

Toyota FJ Cruiser and Prado

W93205

$140.00

$618.00

Toyota FJ Cruiser and Prado

TRCHILUXDD

$154.00

$632.00

LandCruiser 200 Series and Lexus LX

TRCLC200DD

$180.00

$658.00

Isuzu D-Max, MU-X and Mazda BT-50

TRC9015

$216.00

$604.00

LandCruiser 200 Series

W93214

$232.00

$710.00

Isuzu D-Max 2019-on and MU-X 2021-on

W93577

$238.00

$626.00

LandCruiser 100 Series and Lexus LX

TRCLC100DD

$371.00

$849.00

LandCruiser 100 Series IFS

W93241

$422.00

$900.00

Volkswagen Amarok 2H 4Motion to 2015

W93223

$467.01

$1,125.01

Toyota Fortuner and HiLux N70, N80

W93578

$478.50

$866.50

Toyota HiLux N70 and N80 2005-2025

TRC9007

$485.00

$873.00

Holden Colorado and Trailblazer RG, D-Max and MU-X

TRCCOLDD

$510.00

$1,168.00

Holden Colorado, Trailblazer, D-Max and MU-X

W93224

$541.00

$1,199.00

Toyota HiLux N90 2025-on

TRC9023

$590.00

$1,068.00



All prices AUD. Some kits are on preorder, including the N90 kit with stock due 23 November 2026.

Why the range is so wide

Four things move the number.

How much has to come apart: Some platforms take a straightforward spacer and longer fastener arrangement at existing mounting points. Others need the crossmember unloaded and the diff supported while brackets are swapped, which is a longer job. That difference is most of the gap between a $604 fitted price and a $1,199 one.

What is in the kit: A simple puck or spacer kit is fewer parts than a bracket and crossmember kit designed to relocate the diff and keep its mounting integrity intact. More engineering in the kit means more in the price.

Whether anything else has to move: On some vehicles the drive shaft, sway bar link or a skid plate has to be adjusted or repositioned to suit the new diff height. Any of those steps adds labour to the job.

Whether the front end is already apart: This is the one you control. Fitted at the same time as your lift, almost all the labour is already being paid for. Booked separately, you pay to strip the same front end twice.

Fitting with the lift versus fitting later

Scenario

What you pay for

Diff drop fitted during the lift install

Kit, plus a small amount of additional labour

Diff drop fitted as a separate later job

Kit, plus the full labour to strip and reassemble the front end

Diff drop fitted with CV replacement after wear

Kit, plus CV assemblies, plus labour, plus an alignment



The third row is the expensive one, and it is the one people end up in when they treat the kit as optional. The comparison that matters is not the kit price against zero. It is the kit price against a pair of front CV assemblies on a ute you have already spent money lifting.

What is and is not included in the fitted price

The fitted price covers the kit and its professional installation at a Click and Fit location. It does not include a wheel alignment, and a 2 inch lift needs one regardless of whether you add the diff drop, so budget for that separately. It also does not include any other correction parts your build may need, such as upper control arms for caster.

If you are pricing a whole lift build, get the lift, the diff drop, any control arms and the alignment quoted together. One visit is cheaper than three and you get a single alignment at the end.

FAQs

How much does a diff drop cost in Australia?

Our kits run from $140 to $590 for the kit alone, and $604 to $1,199 fitted through Click and Fit. The figure depends on the platform, because some front ends need far more disassembly than others.

How much is a diff drop for a Hilux?

The N70 and N80 kit TRC9007 is $485.00, or $873.00 fitted. The N90 2025-on kit TRC9023 is $590.00, or $1,068.00 fitted. Prices AUD at time of writing.

How much is a diff drop for a D-Max or BT-50?

The TRC9015 kit for the Isuzu D-Max, MU-X and Mazda BT-50 is $216.00, or $604.00 fitted. The W93577 kit for the 2019-on D-Max and 2021-on MU-X is $238.00, or $626.00 fitted.

Why is one kit $140 and another $590?

Kit content and installation complexity. A spacer style kit using existing mounting points is far simpler than a bracket and crossmember kit that relocates the differential, and the labour to fit each differs accordingly.

Is it cheaper to fit a diff drop with the lift?

Yes, clearly. The front end is already apart during a lift install, so you pay for the part and a small amount of extra labour rather than a second full strip down.

Does the fitted price include a wheel alignment?

No. A 2 inch lift needs an alignment whether or not you fit a diff drop, so quote that separately as part of the build.

Can I supply my own kit and have you fit it?

Talk to your local store. Fitted pricing is built around our own range, so a supplied part is quoted case by case.

How long does the installation take?

We have multiple payment options available full all products for Click & Fit and online purchases.

See current pricing for your vehicle on the diff drop kits pages, or ask a store to quote the whole build in one go.
